Portable Cordless Metal Analyser

Oxford Instruments (UK) have introduced a new portable arc / spark metal analyser, the PMI-MASTER Smart. It is the only true portable and full range optical emission spectrometer in the market, designed for metal analysis especially in hard to reach places. Despite its 33 lbs/15kg light weight and compact dimensions, the PMI-MASTER Smart offers full analysis functions and high performance. The powerful rechargeable battery pack and well thought-out transportation concept complement the mobility.

Metal analysis, grade identification and sorting – the PMI-MASTER Smart offers the full range of analysis functions. In comparison to other compact size OES analysers, it offers a wide wavelength range at optimum resolution. The patent pending optics, made of carbon fibre, is the key. Mechanical expansion and tension, triggered by temperature changes and distortion due to change of position are virtually eliminated, guaranteeing stable measuring results. “Our goal was to develop a truly portable metal analyser without compromising on the functions and analysis quality. The PMI-MASTER Smart even exceeded our own targets.” says Vito Angona, General Manager of Oxford Instruments Analysis GmbH.

Power connections are typically not available in hard to reach places. Equipped with a rechargeable and optional replacement battery pack the PMI-MASTER Smart is truly cordless and completely independent from mains supply. The battery pack provides power for the analysis of some hundred samples in ARC and/or SPARK mode, and 7 hours in standby. It also can be operated with the external power supply / charger, with or without battery and even during recharging.

The cases for the transportation of the PMI-MASTER Smart and its accessories easily fit into a car boot. Stacked up they can be dragged with a foldable trolley. For more intensive use a cart, holding a 10l bottle of Argon, probe and all accessories is also available. If you need to climb up to reach the place of analysis, the PMI-MASTER Smart can safely be carried on the back with the back pack frame.

Registered office: Tubney Woods, Abingdon, Oxon, OX13 5QX. Registered in England, number 1044063.

Three different probes are available for the PMI-MASTER Smart. The UVTouch probe analyses low carbon content (L grade separation) besides many others, the arc probe sorts different metals with Arc in air atmosphere in only 3 seconds, the rugged spark probe analysis standard elements with minimum Argon consumption (Linde ECOCYL 1l Argon bottle recommended).
