New Flue Gas Flow Measurement System

PCME Ltd (UK), leading specialist in the development, manufacture and supply of continuous particulate emission monitors, introduce the STACKFLØW 400 designed specifically to monitor the flow rate of emissions from industrial sources complying with the European Monitoring Standard EN ISO 16911-2.

Suitable for measuring flue gas flow rates after both bag filter and electrostatic precipitator arrestment plant, the STACKFLØW 400 utilises a patented Ultrasonic measurement principle for high accuracy while permitting reliable operation in contaminated environments. Importantly, the system is engineered with in-built self-checks and high quality assurance features which satisfy emission release data reporting obligations from a regulatory perspective. Typical applications include waste to energy and incineration plants, emissions from Steel, Chemical and Mineral processing applications, Gas Turbines and Coal-fired Power Plant.

Recently approved to stringent MCERTS and QAL1 standards by TUV, as specified in EN-15267-3 and EN ISO 16911-2, the STACKFLØW 400 provides a complete solution for flow measurement according to EN 14181.

Based on PCME’s long experience of particulate emission measurement in industrial applications, the STACKFLØW 400 is designed for ease of installation and when implemented with the angled sensor option, permits retrofit to a single stack port without the need for fitting a special 45o angled port. In addition, due to the unique extended measurement path (400mm), accurate and increased repeatable measurement is assured. Stack velocity, volumetric flow and pollutant mass release calculations can be achieved when linking the STACKFLØW 400 to gas and dust CEMS.

PCME will be exhibiting at AQE 2015, stands 64 and 75.
