Climate Does Matter-Uncertainty in Air Quality Networks

Aug 26 2022

Author: Dr. John Saffell on behalf of Cogdem

Free to read

Articles are free to download. Unlock the article to be shown more content, graphs and images.

Air quality monitoring stations (termed Automatic Urban and Rural Networks- AURNs in the UK) us either certified reference or equivalent instrumentation. They are trusted for their accuracy and uncertainty to measure air pollutants, monitoring compliance with the legislated Limit Values for gases and particles. Unfortunately, we cannot afford to deploy the number of AURNs needed to properly map our urban air pollution. To remedy this situation, we now have low cost air quality (AQ) networks, comprising from ten to hundreds of sensor systems throughout an urban area, providing near-real time pollution maps. Their cost is about 5% the cost of an AURN, but ensuring their calibration is a serious problem and is the focus of much current research, with Machine Learning (ML)1,2, baseline correction3 and reference co-location4 being three popular calibration methods.

One problem without a solution is the simple fact that most low cost AQ networks are built and calibrated in either Europe or North America, in temperate climates. They are then deployed globally, especially in the most polluted cities in countries including India, Pakistan, China and Mexico; the climates are very different from where they were calibrated. Does that matter? Yes, climate matters. Temperature, humidity and pressure change continually, with different environmental profiles in different climates. This is important because low cost sensors also respond to temperature, humidity and pressure, leading to potentially significant errors in the reported pollutant concentrations.



Environmental Effects on Low Cost Sensors

Four technologies dominate sensors for low cost AQ sensor systems: electrochemical gas sensors and metal oxide chemresistors for gases, laser scattering for particulate matter (PM) and non-dispersive infrared (NDIR) for CO2 and other gases. How do they each respond to environmental conditions?
Electrochemical cells generate a current as they either oxidise or reduce the target gas. Their temperature dependence is provided by sensor manufacturers but rapid temperature changes cause transients that can take hours to restabilise. Hot temperatures (>35°C) create high background currents which is very troublesome when measuring ppb concentrations. Importantly, humidity affects the sensor electrochemistry and rapid humidity changes generate excess current from the sensor, like a supercapacitor, resulting in large current transients6. These transients are difficult to model and are the largest source of data variance when using AQ sensor systems in a dynamic climate. Atmospheric pressure changes are usually slow and have negligible effect, but sudden air flow changes (e.g. ventilation systems) can cause transients which recover in a few minutes.
Metal oxide (MOx) sensors change resistance as the target gas interacts with the metal oxide surface. MOx sensors are relatively free of ambient temperature effects because they should operate at fixed high temperatures, but humidity has a significant effect by changing the surface chemistry, especially with n-type MOx sensors such as SnO2 based sensors. Applying RH correction algorithms are only partially successful because the sensors drift with time, away from the correcting algorithm. MOx sensors are used in lowest cost AQ networks, but due to their humidity dependence and drift, are mostly avoided in the higher quality AQ sensor systems. Again, pressure has a small effect and can be easily corrected.
Particles are detected with laser scattering to measure PM1, PM2.5 and PM10. Scattered light is measured either from single particles (Alphasense, Particle Plus), providing real time particle diameter distributions or scattering from an entire ensemble, calibrated to correlate with PM2.5 (Plantower, Sensirion, Tera, Shinyea…). Both methods have a temperature dependence which can be compensated, but at humidity above 60 %RH the particles adsorb water7, swelling to a larger apparent diameter. Equivalent grade PM instruments (typically $10,000) include high power inlet heaters to dry particles, but this is missing from low cost PM monitors due to power and cost restrictions, Tera being an exception. Climates with high humidity require either particle heating or humidity correction algorithms with their limitations; if not corrected, PM values will be seriously overestimated at high humidity, especially above 85%RH. Pressure variations are not a direct problem but the air flow rate must be controlled and ambient pressure will slightly affect the air flow rate.
Non-dispersive infrared (NDIR) spectroscopy is the most popular technology for measuring CO2, a critical gas for climate warming and a product of combustion. Temperature compensation is critical, but most manufacturers take care of this by expensive factory multipoint temperature calibration. Humidity does not directly affect NDIR at the CO2 wavelength, but fog and rain can condense on the optics causing errors.  Pressure has a linear effect on the observed NDIR light absorbance, so must be corrected, usually with a low cost absolute pressure sensor. If there is no pressure correction then measurements are referenced to the ambient pressure at the time of factory calibration and should be post-process corrected.



Weather, Climate and Environmental Conditions

Daily weather will affect low cost sensors with hot or cold temperature, or dry or high humidity. We cannot predict weather weeks ahead, but we do know the climate which is the average weather behaviour for any location on this planet. In the long term, climate with high temperatures, frequent and rapid humidity changes or long term high humidity will affect the overall performance of AQ networks. But climates are also defined by their seasons7.
Away from the equator there are four seasons, but when discussing environmental conditions both Spring and Autumn are considered to be equivalent: the average temperature will start from either high or low and finish the season either low or high; pressure, temperature and humidity fluctuations are frequent. Winter and Summer have more stable conditions with less fluctuations. Equatorial locations have either no seasonal differences or simply wet and dry seasons.
Climate can be classified in many ways, the Köppen–Geiger climate classification is the most common classification. The table above lists the 20 classifications which are habitable.



How do climates compare?

Let us look at three very different climates: very humid Glasgow (Cfb: courtesy Ricardo plc), Hot and humid Hong Kong (Cwa: courtesy Dane Westerdahl) and hot Mediterranean Los Angeles (Csa: courtesy Raul Dominguez SCAQMD). Diurnal patterns for Hong Kong and Diamond Bar in Los Angeles both show expected midday temperature rises but the average temperature and range of humidities are quite different. Likewise, there are clear seasonal differences between January and July.
We can see that there are differences in both the average temperature and humidity and the daily fluctuations. Annual profiles for the year of 2021 (below) for the two locations show the wide range and variations of temperature and relative humidity, with Hong Kong on the average 15°C hotter and 30% higher humidity.
It would be surprising if an AQ sensor system network that was calibrated in one climate remained accurate in another climate. The red plots to the left show  diurnal, weekly and monthly relative humidities in Glasgow in 2021. It is best to visit in the spring. While diamond Bar in Los Angeles averages about 50% RH, Glasgow averages between 65% and 85% RH.
When we look at the time traces of temperature and relative humidity, it is clear that some climates can present severe environmental conditions for low cost AQ sensor systems.



Are field trials in one climate valid?

Dozens of peer reviewed papers have published results from field trials of low cost AQ sensors systems, although there have been few published results for entire AQ sensor system networks; Breathe London, a long running AQ network field trial is the exception. The locations for sensor system field trials have
been in various climates: Finland, London, Delhi, Nairobi, Boston, Los Angeles, Belgium, Stuttgart, Beijing are just a few sites,
each with their own climate and resultant environmental conditions. Results have been inconsistent for several reasons: different quality sensors, different sensor system constructions, various ML and regression analysis correction algorithms and different climates. The results are variable with the best performance from field trials in mild climates during winter or summer months.
Concern about the data quality from low cost AQ sensor systems is driving standards committees to set Data Quality Objectives (DQOs) for these sensor systems. To achieve the DQO, sensor systems must be tested in the laboratory, in the field, or in both environments. CEN standard committee TC264 WG42 has set two paths for DQO validation: either by extensive field trials or by both shorter field trials and laboratory testing (TS 17660-1:2021). This Technical Specification demands field trials in at least two sites (four sites for the extended field trials) during two seasons, confronting this climate variation problem. ASTM D22.03 is writing a similar Practice Standard (WK64899), also demanding field trials. However, neither document specifies that sensors are tested in extreme climates, so the result
is that sensor systems (not sensor networks) can be tested
in milder climates and manufacturers can claim they meet
the DQO in all climates, although TS 17660 does warn about climate limitations.



Can we do better?

We can do better. It is assumed that if a sensor system passes in a climate with a certain temperature/ humidity regime, it will perform adequately when the temperature and humidity ranges in another climate are less extreme than the test site. Field trials in climates with severe temperature and humidity extremes during field trials should qualify the sensor system for use in less severe climates.
We can view climates in the Köppen table more simply as mixtures of hot/ cold and wet/ dry. These can be combined to provide four climate scenarios: hot/ dry, hot/ wet, cold/ dry and cold/ wet.  We consider cold/dry to not be as severe as cold/ wet, so three climate categories should be tested. In addition, rapid weather changes also stress test sensor system performance, so a fourth climate of changeable weather should be included. The above table lists possible extreme and mild climates in the four categories.
Discussions are beginning amongst certifying bodies, national laboratories and test houses to set up global test sites for validating sensor systems in different climates, ensuring they meet DQOs set by standards committees, following Directives and legislation. VACUUMS, a European project, tested many systems; Marylebone in London has been a test site for various sensor systems; and the current AQ-SPEC program, operated by South Coast Air Quality Management Division (SCAQMD) in Los Angeles has tested many sensor systems, with all test results available on their website. Field trials can be run reliably in different climates, we need to expand to include test sites with more extreme climates.
Low cost AQ sensor systems and networks fulfil a needed requirement to monitor our air pollution in all major urban centres globally. Commercial sensor systems are available from many manufacturers, we now need to build the trust that they can provide good quality data. The first step is Test Specifications and Practice Standards from standards committees, the next step is globally recognised test sites that ensure data quality in all climates.



References

1 Nowack et al Atmos.Meas.Tech.,14,5637–5655,2021 doi.org/10.5194/amt-14-5637-2021
2 Patra et al Building and Environment, doi.org/10.1016/buildenv.2020.107457
3 Popoola et al, Atmospheric Environment doi.org/10/1016/j.atmosenv.2016.10.024
4 Rogulski et al, ACS Sensors 2016,22,3619 doi.org/10.3390/s22103619
5 Hitchman, Saffell ACS Sensors 2021 6 (11), 3985-3993 doi.org/10.1021/1c01339
6 Ouyang, ACS Sensors 2020 5 (9), 2742-2746 doi.org/10.1021/acssensors.0c01129
7 Han et al, ACS Sensors 2021,21,256 https://doi.org/10.3390/s21010256
