Air Monitoring
Continuous Ambient Air Pollutant Eminence Monitoring System - Model: AAPQMS-19C
Aug 14 2017
AAPQMS-19C is an indigenously manufactured for Continuous Monitoring of Environment parameter such as Particulate Matters, Gases, Temperature, Humidity and Atmospheric Pressure in the air. System has facility to incorporate with Meteorological parameter measurements.
Immediate measurement of the concentration of gases & dusts present in a specific location both urban and industrial for evaluating the environmental safety degree in a working area. Can also be use on moving vehicles such as mobile laboratories, trains etc., Controlling & checking the forecast modeling of the pollutants concentration in the atmosphere, Measuring the concentrations of the pollutants inhaled by a person during a day, Mapping an area with respect to the concentration of the atmospheric pollutants.
This measuring system has been designed for making reliable continuous measurements without the presence of operators.
The system is designed for Continuous Monitoring Application to be installed open to sky at the prescribed monitoring location & ensures Water & Dust Proof IP65 level protection.
The Microprocessor & Logic Controller based technology helps the system to perform accurately & efficiently. The gas sensing technology is linear, hence need only two-point calibration and are calibrated by sensor manufacturers in laboratories under controlled concentration and ambient conditions. The final readings displayed are calculated after temperature compensation calculation formula. The methodology used for Real Time Dust Concentrations measurement, expressed as PM-10, PM2.5 & PM1.0 monitoring in the air and for classifying them depending on their dimensions is “Laser Scattering” without using external impactors.
An instantaneous reading of the level of pollutants is displayed at the location of system installed (Optional feature).
Meets the measurement requirement of EN 481
It offers a facility for interfacing to a IoT based Real Time & Date Acquisition, Monitoring and FTP interface protocol to transfer RTD data to centralized station data Network via Ethernet / 3G,4G (GSM/GPRS) Interface.
The System ensures reliability, Low Maintenance, Long term calibration stability, Insensitiveness to vibrations, No radioactive source, No need for shelter, High resolution readings at low cost, No Pre-heating time required, Non-corrosive components, Data Logging of instantaneous, Stored reading can be viewed on-line on our Cloud server.
