Development of analytical methods to assess antimicrobial contamination in the environment and its transfer in the food chain

Feb 06 2024

Author: I. Vergara-Luis, N. Bocayá, J.C. Baez Millán, M. Irazola-Duñabeitia, M. Lacuesta, M.Olivares and A. Prieto on behalf of University of the Basque Country

Free to read

Articles are free to download. Unlock the article to be shown more content, graphs and images.

The extensive use of antimicrobials (AMs) in agriculture has led to the occurrence of residual drugs in different environmental matrices such as animal manure (Zalewska et al., 2021), soils (Hang et al., 2021) and vegetables (Kang et al., 2013) frequently consumed by humans, among others. This could pose a potential threat to human health, not only because of the possible effects after ingestion but also because the transmission of AM-resistant genes could occur (Jadeja & Worrich, 2022).

In  this sense, two accurate sample preparation procedures were developed and validated for the simultaneous analysis of sulfonamides (SAs) and tetracyclines (TCs) in four of the most widely consumed vegetables (lettuce, onion, tomato, and carrot) in Europe (Vergara-Luis, Báez-Millán, et al., 2023). The evaluated protocols were based on QuECHERS (Quick, Easy, Cheap, Effective, Rugged and Safe) for extraction and subsequent clean-up by SPE (solid phase extraction) or dispersive SPE. Parameters affecting both extraction and clean-up were carefully evaluated and selected for accuracy of results and minimal matrix effect (Figure 1).
Overall, apparent recoveries were above 70 % for most of the target analytes with both analytical procedures, and adequate precision (RSD < 30 %) was obtained for all the matrices. The procedural limits of quantification (LOQPRO) values for SPE clean-up remained below 4.4 μg·kg-1 for TCs in all vegetables except for chlortetracycline (CTC) in lettuce (11.3 μg·kg-1) and 3.0 μg·kg-1 for SAs, with the exception of sulfadiazine (SDZ) in onion (3.9 μg·kg-1) and sulfathiazole (STZ) in carrot (5.0 μg·kg-1). Lower LOQPRO values (0.1-3.7 μg·kg-1) were obtained, in general, when dSPE clean-up was employed. Both methods were applied to twenty-five market vegetable samples from ecological and conventional agriculture and only sulfamethazine (SMZ) and sulfapyridine (SPD) were detected in lettuce at 1.2 μg·kg-1 and 0.5 μg·kg-1, respectively.
Moreover, an accurate analytical method was also developed for the simultaneous analysis of twenty-four AMs in soil:compost and animal manure samples by means of Ultra-High Performance Liquid Chromatography coupled to a triple-quadrupole mass spectrometer (UHPLC-QqQ) (Vergara-Luis, Bocayá, et al., 2023). For this purpose, the effectiveness of two extraction techniques (i.e., focused ultrasound solid-liquid extraction (FUSLE) and QuEChERS was evaluated and the clean-up step using solid phase extraction (SPE) was also thoroughly studied (Figure 2).
The method was successfully validated at 10 μg·kg-1, 25 μg·kg-1 and 50 μg·kg-1 showing adequate trueness (70-130 %) and repeatability (RSD<30 %), with few exceptions. Procedural limits of quantification (LOQPRO) were determined for soil:compost (0.45 to 7.50 μg·kg-1) and manure (0.31 to 5.53 μg·kg-1) samples. Pefloxacin could not be validated at the lowest level since LOQPRO ≥ 10 μg·kg-1. Sulfamethazine (7.9 ± 0.8 µg·kg-1), danofloxacin (27.1 ± 1.4 µg·kg-1) and trimethoprim (4.9 ± 0.5 µg·kg-1) were detected in soil samples; and tetracycline (56.8 ± 2.8 µg·kg-1), among other AMs, in the plants grown on the surface of the studied soil samples. Similarly, SAs, TCs and fluoroquinolones (FQs) were detected in sheep manure in a range of (1.7± 0.3) - (93.3± 6.8) µg·kg-1. Soil and manure samples were also analysed through UHPLC coupled to a high-resolution mass-spectrometer (UHPLC-qOrbitrap) in order to extent the multitarget method to suspect screening of more than 22,281 suspects. A specific transformation product (TP) of sulfamethazine (formyl-sulfamethazine) (Figure 3) was annotated at 2a level in manure samples, among others.

Figure 3. Chemical structure of the identified TP, formyl-sulfamethazine.

This work contributes to the efforts that have been made in the last decade to develop analytical methods that allow multitarget analysis of a wide variety of AMs, including TPs, in complex environmental matrices, which is a complex task due to the diverse physicochemical properties of the AMs. Furthermore, the results of this work not only demonstrated the presence of AMs in the environment and the transference of these pharmaceuticals in the manure-soil-plant/vegetable chain, which puts pressure on bacteria to create resistance, but also showed the presence of their TPs, the effects of which are still unknown.



Hang, L., Zhao, Y., Liu, C., Yu, Y., He, Y., Xu, J., & Lu, Z. (2021). Determine Multiple Classes of Veterinary Antibiotics in Soil: Comparing Dispersive and Solid-Phase Extraction for Sample Cleanup. Chromatographia, 84(9), 833-844. https://doi.org/10.1007/s10337-021-04064-5 Jadeja, N. B., & Worrich, A. (2022). From gut to mud: Dissemination of antimicrobial resistance between animal and agricultural niches. Environmental Microbiology, 24(8), 3290-3306. https://doi.org/10.1111/1462-2920.15927
Kang, D. H., Gupta, S., Rosen, C., Fritz, V., Singh, A., Chander, Y., Murray, H., & Rohwer, C. (2013). Antibiotic Uptake by Vegetable Crops from Manure-Applied Soils. Journal of Agricultural and Food Chemistry, 61(42), 9992-10001.
https://doi.org/10.1021/jf404045m Vergara-Luis, I., Báez-Millán, J. C., Baciero, I., González-Gaya, B., Olivares, M., Zuloaga, O., & Prieto, A. (2023). Comparison of conventional and dispersive solid phase extraction clean-up approaches for the simultaneous analysis of tetracyclines and sulfonamides in a variety of fresh vegetables. Talanta, 254, 124192.
Vergara-Luis, I., Bocayá, N., Irazola-Duñabeitia, M., Zuloaga, O., Lacuesta, M., Olivares, M., & Prieto, A. (2023). Multitarget and suspect screening of antimicrobials in soil and manure by means of QuEChERS — liquid chromatography tandem mass spectrometry. Analytical and Bioanalytical Chemistry, 415, 6291-6310.
Zalewska, M., Błażejewska, A., Czapko, A., & Popowska, M. (2021). Antibiotics and Antibiotic
Resistance Genes in Animal Manure – Consequences of Its Application in Agriculture. Frontiers in Microbiology, 12, 610656. https://doi.org/10.3389/fmicb.2021.610656
