Environmental Laboratory

Poly and perfluoroalkylated substances (PFAS); the gathering storm for chemical regulatory professionals and the industry

Jan 30 2023

Author: Dr Emma Pemberton on behalf of Ricardo

Free to read

This article has been unlocked and is ready to read.

Download

What are PFAS?

Per- and polyfluoroalkylated substances (PFAS) are a very large and structurally diverse group of man-made organo-fluorine substances. They are sometimes termed ‘forever chemicals’ because of their extreme persistence. Well known examples of PFAS are perfluoroctanoic acid (PFOA) and perfluorooctane sulfonate (PFOS), both of which are now subject to regulatory restrictions because of their harmful properties.

he OECD1 global working group on PFAS defines this group of chemicals as “fluorinated substances that contain at least one fully fluorinated methyl or methylene carbon atom (without any H/Cl/Br/I atom attached to it)…any chemical with at least a perfluorinated methyl group (–CF3) or a perfluorinated methylene group (–CF2–) is a PFAS”. This definition is based purely on chemical structure. Identification of a substance as a PFAS does not necessarily mean that it is toxic1. Estimates of the number of substances that meet the PFAS definition vary from 4,7001 to over 6,000,0002. The number of PFAS in commercial use and supply in the UK is unknown but likely to be much lower3.
PFAS have been in commercial production and use since the mid-20th century. They were first used in fire-fighting foams in the 1960s. They are used globally in many industrial applications and consumer products. Their high thermal and chemical stability and their water- and oil-repellent nature encouraged their wide use in consumer products such as cosmetics, coatings for textiles and paper including food contact materials. PFAS also have many industrial applications including metal electroplating, polymer and semi-conductor manufacture  amongst many more.



Why are they a concern?

PFAS are extremely stable because the carbon-fluorine bond is very strong. Their extreme persistency means that environmental exposure could be irreversible and that PFAS are technically difficult and costly to clean-up and destroy. Many PFAS are environmentally mobile and travel far from their source, leading to widespread contamination of environmental waters including sources used for drinking water supply. Shorter chain PFAS with a fluoroalkyl chain less than six carbon atoms are more mobile than longer chain substances and are frequently found in environmental waters including those used for drinking water supply. Longer chain PFAS have a greater propensity to bioaccumulate in the food chain, with reports of PFAS in human tissue and blood, in plants following uptake from soil and in animals such as fish. A recent European biomonitoring study4  found that serum levels of PFAS exceeded safe thresholds in over 14% of teenagers sampled.
Exposure to some PFAS has been associated with a range of adverse effects on human health. These include altered immune and thyroid function, increased cholesterol, liver disease, reduced birth weight and adverse reproductive and development outcomes4. However, for most PFAS there is very little toxicological data. This is a high priority evidence gap that both scientists and regulatory authorities are seeking to rapidly address globally.
With so many uses of PFAS, there are numerous pathways of release to the environment across the full life-cycle of the substance from manufacture through use to disposal. PFAS are ubiquitous in the environment with contamination of remote areas by some PFAS reported. Higher environmental concentrations of PFAS are often associated with their use in firefighting foams at airports, fire training grounds, military sites, and major incident sites. Secondary sources of PFAS to the environment include wastewater treatment works and landfill sites. Research has been on-going in the UK by the Environment Agency to identify high risk sites associated with PFAS use. A useful summary of the evidence base on use and environmental occurrence of PFAS in England was published by the Environment Agency in 20213, with further sampling for a broader range of PFAS continuing in groundwater and surface waters planned.



Current and future UK and European PFAS policy

The hazardous and potentially ubiquitous nature of several PFAS has been recognised since the early 2000s when PFOS was voluntarily withdrawn from use by industry. Several PFAS are subject to global regulatory restrictions. PFOS was designated as a persistent pollutant (POP) under the Stockholm Convention6 in 2009, followed by PFOA in 2020 and perfluorohexane sulfonate (PFHxS) in 2022. In addition, several PFAS are identified under the REACH regulations7 as Substances of Very High Concern (SVHC) and subject to restrictions on manufacture, supply and use in the European Union and the UK. Concerns related to the persistent, bioaccumulative and toxic (PBT) properties of PFAS historically underpinned these restrictions. More recently, the high persistence and high mobility of PFAS have led to restrictions of other PFAS such as hexafluoropropylene oxide dimer acid (HFPO-DA) also known as Gen-X, based on an ‘equivalent level of concern’. A substance-by-substance approach to risk management has led to several cases of regrettable substitution, with one hazardous substance being replaced by another. For example, the restriction prohibiting use of PFOS in fire-fighting foam led to replacement with shorter chain PFAS chemistries which are now known to have equally undesirable properties and are widely detected in environmental waters and soil.
The regulatory landscape is changing very rapidly with much tighter legislation anticipated including widespread restrictions on manufacture and use of PFAS in the EU, as well as other global jurisdictions. The scale of environmental contamination, the extreme persistency and harmful properties and the large number of PFAS has led the European Commission to making a commitment in 2020 in its Chemical Strategy for Sustainability, to phase out all non-essential uses of PFAS. In January 2022, a REACH restriction dossier was submitted on the use of PFAS in firefighting foams and five European Member States have very recently submitted a restriction proposal to the European Chemical Agency (ECHA) to restrict all other uses of PFAS, known as the ‘universal restriction’. ECHA will publish the proposal on 7th February 2023 and a six-month consultation is planned to commence on 22 March 2023.
In the UK a regulatory management options analysis (RMOA) is currently being prepared under UK REACH regulations by the Environment Agency and is expected to be published in early 2023. It is not yet known if the UK will follow the same approach as the EU and propose a ‘universal ban’ on all PFAS or target specific uses or groups of PFAS.
The EU Water Framework Directive (WFD) and Environmental Quality Standards Directive currently lists only one PFAS – PFOS as a priority hazardous substance, with a biota based Environmental Quality Standard (EQS) of 9.1µg/kg wet weight and annual average EQS in water of 6.5 x 10-4 µg/l for inland surface waters and  1.3 x 10-4 µg/l for other surface waters. It is evident that when considering risk management of PFAS, the issue is far broader than PFOS. The Scientific Committee on Health, Environment and Emerging Risks (SCHEER) recently published an opinion9 on a proposal for additional EQS for several PFAS under the WFD. It is not yet known if the UK will follow a similar route and develop additional EQS for PFAS, but it is likely given the wider awareness and supporting evidence base to indicate PFAS require wider risk management than simply focusing on a single substance, PFOS.
The recast European Drinking Water Directive10 specifies thresholds for both sum of PFAS and total PFAS. In the UK, the Drinking Water Inspectorate (DWI) have recently published updated guidance on tiered risk assessment for PFAS11 ; requiring water companies to identify sources of PFAS in their catchments and assess risk by considering proximity to sources, catchment flows, and hydrological conditions.
Managing the risk to the environmental and public health risks from PFAS is a significant global challenge requiring actions to tackle both legacy contamination from historical use of withdrawn substances and manage emissions from currently used PFAS. The scientific understanding and evidence base on hazards and effective approaches to managing risk and cleaning up existing contamination are rapidly evolving.

Author Details

Dr. Emma Pemberton
E: ncec@ricardo.com
T: +44 (0)1235 753654/ +1-855-220-0214
For more information on how NCEC, the chemical experts at Ricardo, can help you identify and transition away from PFAS, please visit: the-ncec.com/pfas
